The Ultrachoc project, funded by the EU under the Seventh Framework Programme, aims to give chocolate manufacturers more consistent quality in products by controlling and monitoring cocoa butter crystallization with ultrasound.
Tempering is a process in chocolate manufacturing that involves mixing and cooling liquid chocolate under controlled conditions to ensure cocoa butter crystallizes in Form V, the most desirable of six possible crystal types. Incorrect tempering results in chocolate with a soft texture that is dull in color and difficult to de-mold.
Real-time crystallization monitoring
Ultrachoc hopes to use ultrasound to manage the crystallization process and incorporate real-time analysis.
Adriana Delgado, project manager of Ultrachoc who works in novel technologies for IRIS, told ConfectioneryNews.com: “The idea is to control the tempering process online”.
She said that under current technology chocolate makers analyzed crystallization offline by regularly taking chocolate samples to labs to determine the level of solid fat content (SFC) in the tempering machine at the temperature where mostly type V crystals can survive. IRIS said that traditional methods of SFC determination were slow, irreproducible and required additional chemicals.
The consortium
Carla (Czech Republic)
Seaclaidi Na Sceilge Teoranta (Ireland)
Aktive Arc Sarl (Switzerland)
Ubertone Sas (France)
Prefamac Nv (Belgium)
Nestec York Ltd (United Kingdom)
Chocolates Valor SA (Spain)
SIK-Institute foer Livsmedel Och Bioteknik AB (Sweden)
Eidgenoessische Technische Hochschule Zurich (Switzerland)
Delgado said that with ultrasound, manufacturers could avoid these delays using real-time monitoring of the tempering process that would allow companies to adapt the process to obtain the correct tempering. “You are always getting what you want,” she said.
How it works
Ultrachoc will use an ultrasound Doppler-based velocity profile and pressure drop technique (UVPPD) to incorporate an online temper meter.
Lab trials will experiment with ultrasound UVPPD and ultrasound attenuation (USA) techniques, UVPPD+USA, to define parameters needed for an industrial system for chocolate manufacturers.
Ultrasound at high frequencies can be used for analysis, while low frequencies can be used to modify food products. The project will explore using low frequencies to control crystal sizes in chocolate and high frequencies to develop an online sensor.
The project aims to achieve 1-2% solid fat content in the tempering machine at a temperature where mostly Form V crystals can survive.
Delgado said that the technology would be faster than existing tempering, but refused to put a value on the speed at this early stage.
Nuclear Magnetic Resonance is another way to measure SFC in chocolate, but IRIS considers it expensive and said the method could not support an online measurement system.
Affordable for SMEs
According to Delgado, existing temper meter units may cost between €7,000 to €40,000 ($9,100-$52,100). The Ultrachoc project aims to create an affordable ultrasound alternative for SMEs, but Delgado said it was too soon to speculate on price.
The consortium hopes to have a prototype by the end of the two-year project.
A test site is planned towards the end of the project at different SME chocolate manufacturers in the consortium, Skelligs in Ireland and Carla in the Czech Republic, with an additional test site planned at either a Nestlé or Valor plant in Europe.
